Eaton SRH422446W SmartRack 42U Deep Standard-Width Heavy-Duty Rack Enclosure – White
The Eaton SRH422446W SmartRack® 42U Rack Enclosure is engineered for large, heavy AI servers and mission-critical IT applications. Constructed from 2.5 mm thick steel with reinforced structural elements, this enclosure offers exceptional durability, strength, and security. With an expanded 46-inch depth, it accommodates oversized AI servers and other deep equipment that won’t fit in standard racks. The white powder-coated finish enhances visibility inside the rack, making maintenance, cable identification, and port access faster and more accurate.
Its fully locking reversible front door, split rear doors, and removable side panels provide robust physical security and quick access when needed. Perforated doors ensure optimized airflow, while toolless 0U mounting rails and built-in baying brackets make equipment installation and rack expansion straightforward. Pre-installed casters and adjustable levelers allow for easy positioning and stabilization. The SRH422446W also meets PCI DSS compliance requirements, making it an ideal solution for environments handling sensitive data.
Heavy-Duty Construction: 2.5 mm thick steel frame with extra welds, gussets, and reinforced structural elements for maximum strength.
Massive Load Capacity: Supports up to 5,000 lbs. stationary and 3,500 lbs. rolling load.
Extra-Deep Design: 46-inch depth for large AI servers and oversized IT equipment.
Enhanced Visibility: White powder-coated finish improves visibility for installation and maintenance.
Secure Access: Locking reversible front door, split rear doors, and removable side panels.
Optimized Cooling: Perforated front and rear doors promote efficient airflow.
Easy Deployment: Ships fully assembled with pre-installed casters and adjustable levelers.
Toolless Accessories: 0U mounting rails and baying brackets for quick installation and rack expansion.
Compliance: Meets PCI DSS physical security requirements; UL, CE, and RoHS certified.
| Specification | Details |
|---|---|
| Model Number | SRH422446W |
| UPC Code | 037332290144 |
| Color | White |
| Material | Steel |
| Rack Height | 42U |
| Rack Depth | Deep |
| Factory Preset Rack Depth | 34.5 in. (876 mm) |
| Maximum Device Depth | 46 in. (1168 mm) |
| Minimum Device Depth | 4 in. (102 mm) |
| Unit Dimensions (H x W x D) | 79.508 x 23.622 x 49.238 in. (199.39 x 60.02 x 109.22 cm) |
| Unit Weight | 515 lbs. (233.6 kg) |
| Weight Capacity – Stationary | 5,000 lbs. (2,268 kg) |
| Weight Capacity – Rolling | 3,500 lbs. (1,588 kg) |
| Number of Vertical Mounting Rails | 4 |
| Assembly Required | No |
| Grounding Details | Front and rear door frames |
| Built-in Cable Management | No |
| Leveling Feet | Yes |
| Locking | Yes |
| Pre-Installed Casters | Yes |
| Outdoor Use | No |
| Certifications | UL 62368-1, UL 2416 |
| Compliance | CE (Europe), EIA/ECA-310-E, RoHS, UKCA |
| Warranty | 5-year limited warranty |
Eaton SRH422446W 42U Server Rack
(4) Side Panels
(8) Side Panel Locks
(2) Keys
(60) Phillips-Head Mounting Screws (M6 x 5/8 in.)
(60) Nylon Cup Washers
(60) Cage Nuts
Owner’s Manual
