APC SX Gen 2
NetShelter SX Gen 2 Server Enclosures
• Orderable ⓘ
This product is available for order. Lead times vary by product and manufacturer.
A lead time will be provided after the order has been placed, or upon request before ordering.
Request Current Lead Time
Lead time and availability are subject to change without notice.
Product Code:
SX Gen 2
Condition:
New
Shipping:
Calculated at Checkout
Rack Units:
52U
Color:
Black
Width:
29.5"
Width:
31.5"
Depth:
>40"
Features:
AI Infrastructure
Features:
Lift-off Side Panels
Features:
Locking Handle
Rack Units:
48U
MSRP:
$3,505.00
$2,481.25
-->
(You save
$1,023.75
)
NEW & IMPROVED
NetShelter SX Gen 2 has been updated to support AI and higher-density workloads with improved physical infrastructure compared to the Gen 1 version.
Airflow: Door perforation increased from 69% on the first generation to 80% on Gen 2 for significantly better heat dissipation.
Door Opening Angle: Expanded from roughly 130° up to 270° when bayed/lined up at the end of rows, keeping aisles clear.
Security & Locking: Upgraded to a robust 3-point locking system on the front door to better secure heavy, high-value gear.
Load Capacity: Enhanced static and dynamic load ratings (up to 4,000 lbs / 1,814 kg static) tailored for heavy AI and HPC deployments.
Usability & Design: Features exterior-facing hinges with easy tool-free door removal tabs, more accessible leveling feet, and a lower lifecycle carbon footprint with 97% recyclability
Upgrade your IT infrastructure with APC NetShelter SX Gen 2 server racks, engineered to support modern data centers, enterprise server rooms, colocation facilities, and high-density networking environments. Combining a robust steel enclosure with improved load capacity, enhanced airflow management, and flexible equipment integration, these second-generation racks provide a dependable foundation for critical IT infrastructure.
Designed to accommodate servers, network switches, rackmount UPS systems, rack PDUs, and other essential equipment, NetShelter SX Gen 2 enclosures help simplify installation, improve equipment organization, and support efficient rack-level cooling. Available in multiple rack heights, widths, and depths, they offer the flexibility to configure your infrastructure around your equipment requirements and available floor space.
Key Benefits:
-
Enhanced Load Capacity: Supports demanding IT deployments, including high-density server and networking equipment.
-
Improved Airflow Management: Designed to help optimize cooling and manage airflow around critical hardware.
-
Flexible Rack Configurations: Choose from multiple heights, widths, and depths to suit your deployment.
-
Secure, Durable Construction: Robust steel enclosures help protect valuable IT equipment in professional environments.
-
Integrated Infrastructure Compatibility: Works with compatible rack PDUs, cable management systems, airflow accessories, and other NetShelter components.
-
Versatile Applications: Suitable for enterprise data centers, server rooms, colocation deployments, and advanced computing environments.
Whether you're building a new server room, expanding existing rack capacity, or modernizing your data center, APC NetShelter SX Gen 2 racks deliver the strength, organization, and flexibility needed to support evolving IT demands.
|
Specification |
Gen 2 specification |
|---|---|
|
Equipment mounting |
19-inch EIA-310 compatible |
|
Static load capacity |
Up to 4,000 lb (1,814 kg) |
|
Rolling load capacity |
Up to 2,250 lb (1,020 kg) |
|
Front door |
80% perforation; 270° opening |
|
Rear doors |
Split, perforated doors |
|
Side panels |
Split and lockable |
|
Construction |
Steel enclosure |
|
Warranty |
5 years |
|
Color |
Black on the models listed above |
Find the right NetShelter SX Gen 2 rack for your equipment, space, and infrastructure requirements.
|
Model number |
Rack units |
Height |
Width |
Depth |
Configuration |
|---|---|---|---|---|---|
|
AR3100B2 AR3100W2 |
42U |
1,991 mm (78.4") |
600 mm (23.6") |
1,070 mm (42.1") |
Standard width |
|
AR3300B2 AR3300W2 |
42U |
1,991 mm (78.4") |
600 mm (23.6") |
1,200 mm (47.2") |
Standard width, deep |
|
AR3150B2 AR3150W2 |
42U |
1,991 mm (78.4") |
750 mm (29.5") |
1,070 mm (42.1") |
Wide |
|
AR3350B2 AR3350W2 |
42U |
1,991 mm (78.4") |
750 mm (29.5") |
1,200 mm (47.2") |
Wide, deep |
|
AR3380B2 AR3380W2 |
42U |
1,991 mm (78.4") |
800 mm (31.5") |
1,200 mm (47.2") |
Extra-wide, deep |
|
AR3107B2 AR3107W2 |
48U |
2,258 mm (88.9") |
600 mm (23.6") |
1,070 mm (42.1") |
Standard width |
|
AR3307B2 AR3307W2 |
48U |
2,258 mm (88.9") |
600 mm (23.6") |
1,200 mm (47.2") |
Standard width, deep |
|
AR3157B2 AR3157W2 |
48U |
2,258 mm (88.9") |
750 mm (29.5") |
1,070 mm (42.1") |
Wide |
|
AR3357B2 AR3357W2 |
48U |
2,258 mm (88.9") |
750 mm (29.5") |
1,200 mm (47.2") |
Wide, deep |
|
AR3387B2 AR3387W2 |
48U |
2,258 mm (88.9") |
800 mm (31.5") |
1,200 mm (47.2") |
Extra-wide, deep |
|
AR3358B2 AR3358W2 |
52U |
2,436 mm (95.9") |
750 mm (29.5") |
1,200 mm (47.2") |
Wide, extra-tall, deep |
NEW & IMPROVED
NetShelter SX Gen 2 has been updated to support AI and higher-density workloads with improved physical infrastructure compared to the Gen 1 version.
Airflow: Door perforation increased from 69% on the first generation to 80% on Gen 2 for significantly better heat dissipation.
Door Opening Angle: Expanded from roughly 130° up to 270° when bayed/lined up at the end of rows, keeping aisles clear.
Security & Locking: Upgraded to a robust 3-point locking system on the front door to better secure heavy, high-value gear.
Load Capacity: Enhanced static and dynamic load ratings (up to 4,000 lbs / 1,814 kg static) tailored for heavy AI and HPC deployments.
Usability & Design: Features exterior-facing hinges with easy tool-free door removal tabs, more accessible leveling feet, and a lower lifecycle carbon footprint with 97% recyclability
Upgrade your IT infrastructure with APC NetShelter SX Gen 2 server racks, engineered to support modern data centers, enterprise server rooms, colocation facilities, and high-density networking environments. Combining a robust steel enclosure with improved load capacity, enhanced airflow management, and flexible equipment integration, these second-generation racks provide a dependable foundation for critical IT infrastructure.
Designed to accommodate servers, network switches, rackmount UPS systems, rack PDUs, and other essential equipment, NetShelter SX Gen 2 enclosures help simplify installation, improve equipment organization, and support efficient rack-level cooling. Available in multiple rack heights, widths, and depths, they offer the flexibility to configure your infrastructure around your equipment requirements and available floor space.
Key Benefits:
-
Enhanced Load Capacity: Supports demanding IT deployments, including high-density server and networking equipment.
-
Improved Airflow Management: Designed to help optimize cooling and manage airflow around critical hardware.
-
Flexible Rack Configurations: Choose from multiple heights, widths, and depths to suit your deployment.
-
Secure, Durable Construction: Robust steel enclosures help protect valuable IT equipment in professional environments.
-
Integrated Infrastructure Compatibility: Works with compatible rack PDUs, cable management systems, airflow accessories, and other NetShelter components.
-
Versatile Applications: Suitable for enterprise data centers, server rooms, colocation deployments, and advanced computing environments.
Whether you're building a new server room, expanding existing rack capacity, or modernizing your data center, APC NetShelter SX Gen 2 racks deliver the strength, organization, and flexibility needed to support evolving IT demands.
|
Specification |
Gen 2 specification |
|---|---|
|
Equipment mounting |
19-inch EIA-310 compatible |
|
Static load capacity |
Up to 4,000 lb (1,814 kg) |
|
Rolling load capacity |
Up to 2,250 lb (1,020 kg) |
|
Front door |
80% perforation; 270° opening |
|
Rear doors |
Split, perforated doors |
|
Side panels |
Split and lockable |
|
Construction |
Steel enclosure |
|
Warranty |
5 years |
|
Color |
Black on the models listed above |
Find the right NetShelter SX Gen 2 rack for your equipment, space, and infrastructure requirements.
|
Model number |
Rack units |
Height |
Width |
Depth |
Configuration |
|---|---|---|---|---|---|
|
AR3100B2 AR3100W2 |
42U |
1,991 mm (78.4") |
600 mm (23.6") |
1,070 mm (42.1") |
Standard width |
|
AR3300B2 AR3300W2 |
42U |
1,991 mm (78.4") |
600 mm (23.6") |
1,200 mm (47.2") |
Standard width, deep |
|
AR3150B2 AR3150W2 |
42U |
1,991 mm (78.4") |
750 mm (29.5") |
1,070 mm (42.1") |
Wide |
|
AR3350B2 AR3350W2 |
42U |
1,991 mm (78.4") |
750 mm (29.5") |
1,200 mm (47.2") |
Wide, deep |
|
AR3380B2 AR3380W2 |
42U |
1,991 mm (78.4") |
800 mm (31.5") |
1,200 mm (47.2") |
Extra-wide, deep |
|
AR3107B2 AR3107W2 |
48U |
2,258 mm (88.9") |
600 mm (23.6") |
1,070 mm (42.1") |
Standard width |
|
AR3307B2 AR3307W2 |
48U |
2,258 mm (88.9") |
600 mm (23.6") |
1,200 mm (47.2") |
Standard width, deep |
|
AR3157B2 AR3157W2 |
48U |
2,258 mm (88.9") |
750 mm (29.5") |
1,070 mm (42.1") |
Wide |
|
AR3357B2 AR3357W2 |
48U |
2,258 mm (88.9") |
750 mm (29.5") |
1,200 mm (47.2") |
Wide, deep |
|
AR3387B2 AR3387W2 |
48U |
2,258 mm (88.9") |
800 mm (31.5") |
1,200 mm (47.2") |
Extra-wide, deep |
|
AR3358B2 AR3358W2 |
52U |
2,436 mm (95.9") |
750 mm (29.5") |
1,200 mm (47.2") |
Wide, extra-tall, deep |
